TX005 Commercial Electric Treadmill with 32-Inch Touchscreen
The TX005 commercial treadmill features a 0–20 km/h speed range, automatic incline, a 1540 × 620 mm running area and an optional 32-inch touchscreen. Its heavy-duty steel structure is designed for gyms, hotels and commercial fitness facilities.
Quick Facts
- Product type: Commercial electric treadmill
- Speed range: 0–20 km/h
- Incline system: Automatic incline
- Motor: 1.25 HP continuous brushless DC motor; 3.0 HP rating also listed
- Running area: 1540 × 620 mm
- Display: Optional 32-inch LCD/LED touchscreen
- Product dimensions: 2110 × 880 × 1530 mm
- Power supply: 220 V / 8.6 A
Commercial Electric Treadmill with Touchscreen
The TX005 Commercial Treadmill is designed for walking, jogging, endurance running and intensive cardiovascular training in commercial gyms, fitness clubs, hotels and professional training facilities.
Its adjustable speed range of 0–20 km/h supports warm-up walking, steady cardio, distance running and interval workouts. The automatic incline system allows users to increase exercise intensity without manually adjusting the running platform.
The spacious 1540 × 620 mm running area provides sufficient room for different stride lengths and running speeds. A 25 mm running deck and 2.5 mm running belt are listed for the supplied configuration.
The TX005 can be configured with a 32-inch LCD or LED touchscreen. Hand-grip heart-rate sensors provide convenient pulse monitoring during exercise.
Key Features
0–20 km/h Speed Range
The adjustable speed range supports walking, jogging, endurance running and high-intensity cardio exercise.
Automatic Incline
The automatic incline system allows users to increase workout intensity and simulate uphill running.
1540 × 620 mm Running Area
The spacious running surface provides comfortable movement space for different users and stride lengths.
32-Inch Touchscreen Option
An optional 32-inch LCD or LED touchscreen can provide workout information and console control.
Hand-Grip Heart Rate
Integrated hand-grip sensors allow users to monitor heart rate during treadmill workouts.
Commercial Steel Structure
The heavy-duty steel frame provides stable support for regular use in professional fitness environments.
Training Benefits
Cardiovascular Endurance
Walking, jogging and running help improve heart and lung endurance during regular cardio exercise.
Adjustable Training Intensity
Speed and automatic incline settings allow users to adjust workout difficulty according to their training goals.
Lower-Body Conditioning
Treadmill exercise engages the glutes, quadriceps, hamstrings, calves and core muscles.
Indoor Running Convenience
The treadmill provides controlled indoor exercise regardless of outdoor weather conditions.
Technical Specifications
| Model | TX005 |
|---|---|
| Product Name | Commercial Electric Treadmill with Touchscreen |
| Product Type | Commercial electric treadmill |
| Driving Type | Electric |
| Main Material | Steel |
| Speed Range | 0–20 km/h |
| Incline System | Automatic incline |
| Incline Range | To be confirmed before order |
| Listed Motor Rating | 3.0 HP |
| Continuous Motor Output | 1.25 HP continuous brushless DC motor |
| Screen Option | 32-inch LCD/LED touchscreen |
| Standard Display Type | LCD digital display |
| Heart-Rate System | Hand-grip heart-rate sensors |
| Workout Functions | Speed, heart rate, workout programs and available console data |
| Running Area | 1540 × 620 mm |
| Running Belt Thickness | 2.5 mm |
| Running Deck Thickness | 25 mm |
| Folding Function | No |
| Suitable Users | Men and women |
| Application | Commercial gyms, fitness clubs, hotels and professional training facilities |
| Product Dimensions | 2110 × 880 × 1530 mm |
| Net Weight | 180 kg |
| Gross Weight | 220 kg |
| Input Voltage | 220 V |
| Input Current | 8.6 A |
| Plug Type | To be confirmed for the destination market |
| Color Options | Available according to order requirements |
| Custom Packaging | Available |
| Warranty | 1 year |
| Packing Dimensions | 2220 × 1000 × 680 mm |
| Manufacturing Origin | Zhejiang, China |
Commercial Applications
The TX005 is suitable for walking, jogging and running in commercial and professional fitness environments.
Quality and Order Verification
Frame Inspection
The steel frame, welding positions, connection points and fasteners can be checked before shipment.
Motor and Speed Test
The motor, control system and 0–20 km/h speed range can be tested before packaging.
Incline Inspection
The automatic incline mechanism can be tested according to the confirmed production configuration.
Running Belt Inspection
Running belt alignment, roller movement, deck condition and operating stability can be checked before shipment.
Console Inspection
The touchscreen, workout display and heart-rate sensors can be checked before packaging.
Photo and Video Support
Product photos, treadmill operating videos and packing photos can be requested before shipment.
Packaging Information
Frequently Asked Questions
What is the speed range of the TX005?
The TX005 has an adjustable speed range of 0–20 km/h.
Does the TX005 have automatic incline?
Yes. The TX005 is equipped with an automatic incline system. The exact incline range should be confirmed before ordering.
What is the running area?
The TX005 running area measures 1540 × 620 mm.
What motor does the TX005 use?
The supplied specification lists a 1.25 HP continuous brushless DC motor and a separate 3.0 HP motor value. The final motor rating should be confirmed before ordering.
What display options are available?
The TX005 can be configured with a 32-inch LCD or LED touchscreen. The final screen configuration should be confirmed with the order.
Does the TX005 support heart-rate monitoring?
Yes. Hand-grip heart-rate sensors are included in the supplied specification.
Is the TX005 foldable?
The explicit parameter table lists the TX005 as non-folding.
What are the product dimensions?
The TX005 product dimensions are 2110 × 880 × 1530 mm.
What power supply does the TX005 require?
The supplied configuration lists a 220 V input and 8.6 A current. Frequency and plug type must be confirmed for the destination market.
What are the packing dimensions and gross weight?
The packing dimensions are 2220 × 1000 × 680 mm, and the listed gross weight is 220 kg.
Request a Quote for TX005
To receive an accurate quotation, please provide:
- Quantity: Required number of commercial treadmills
- Destination: Country and destination port
- Voltage and frequency: Required electrical configuration
- Plug type: EU, UK, US, AU or another required plug
- Motor configuration: Required continuous and listed motor power
- Incline: Required automatic incline range
- Screen: Standard display or 32-inch LCD/LED touchscreen
- Color: Required frame and exterior color
- Packaging: Standard or customized export packaging
- Inspection: Product photos, operating video or third-party inspection
- Additional requirements: User capacity, spare parts or complete gym project requirements
Model: TX005 | Quantity: ___ | Destination country: ___ | Destination port: ___ | Voltage/Frequency: ___ | Plug type: ___ | Motor configuration: ___ | Incline range: ___ | Screen type: Standard / 32-inch LCD / 32-inch LED | Required color: ___ | Custom packaging: Yes / No | Inspection required: Yes / No | Additional requirements: ___
